Included Models & Specifications
| Item | Diameter | Total Length | Sand Height | Net Weight | Key Applications |
|---|---|---|---|---|---|
| Diamond Core Drill Bit | 2-1/2" (Φ65mm) | 60 mm | 10 mm | 257 g | For large holes in ceramic tiles and porcelain for plumbing or fixture installations. |
| Diamond Core Drill Bit | 1-25/32" (Φ45mm) | 60 mm | 10 mm | 170 g | For medium-sized holes in ceramic tiles or porcelain for light fixtures or electrical installations. |
| Diamond Core Drill Bit | 1-3/8" (Φ35mm) | 60 mm | 10 mm | 133 g | Ideal for drilling smaller holes in ceramic tiles and porcelain. |
| Diamond Core Drill Bit | 1" (Φ25mm) | 60 mm | 10 mm | 93 g | Suitable for precision drilling in ceramic and porcelain tiles. |
| Diamond Core Drill Bit | 4/5" (Φ20mm) | 60 mm | 10 mm | 80 g | For standard hole drilling in ceramic tiles and porcelain. |
| Finger Bit | 4/5" (Φ20mm) | 65 mm | 50 mm | 99 g | Ideal for deeper cuts and larger holes in ceramic tiles and porcelain. |
| Adapter | - | 53-65 mm | - | - | Connects all bits to standard rotary tools such as drills, angle grinders, and more. |
Technical Advantages
• Vacuum Brazed Technology
The drill bits feature vacuum brazing, which ensures longer tool life and superior cutting performance when used on ceramic tiles and porcelain.
• Universal 5/8"-11 Connector
These bits are compatible with standard rotary tools, including drills and grinders, providing versatility in different tasks.
• Wet/Dry Dual Mode
The bits can be used in both wet and dry conditions, offering a clean and efficient drilling experience on ceramic and porcelain materials.
Ideal Work Scenarios
• Ceramic & Tile Drilling
Perfect for precise, clean drilling in ceramic tiles, porcelain, and similar materials used in home renovations, plumbing, and electrical installations.
• Home Renovations
Ideal for installing fixtures, plumbing, and electrical systems in ceramic tiles and porcelain.
Why Choose This Set?
• Comprehensive Range of Sizes: The set includes drill bits from 20mm to 65mm, covering a variety of common tile and ceramic drilling needs.
• Long-Lasting Performance: The vacuum brazing process ensures the bits last longer and resist wear, making them ideal for repeated use in ceramic and porcelain.
• Flexible Compatibility: The 5/8"-11 connector is compatible with most rotary tools, ensuring maximum convenience.
• Dust-Free Drilling: Use with water to achieve dust-free drilling for cleaner work environments.
Customize Your Perfect Drill Set!
Customize your set to meet your specific drilling needs:
• Choose Sizes: From micro sizes (Φ6mm) to larger sizes (Φ150mm).
• Select Connectors: Match the set to your existing tools for greater compatibility.
• Performance Options: Opt for wet/dry variants, various grit densities, or specialized coatings.
OEM/ODM Customization | Bulk Order Discounts
Take advantage of volume discounts and tailored configurations:
• Free Configuration Advice: Our engineers will help design the ideal drill set for your needs.
• Volume Discounts: Get discounts for bulk orders of 100+ sets.
• Fast Global Shipping: Reliable delivery in 10-20 days, with DAP shipping terms.
Contact Us Today for a Personalized Quote!
Vacuum brazed is a process that uses high temperature and low pressure in a vacuum environment to braze. In the vacuum environment, due to the low pressure, the gas will not cause oxidation, hydrogenation or nitriding reactions, so it can be welded with high melting point and difficult to process materials, such as alloy steel, tungsten, molybdenum and so on.
Vacuum brazing, because it does not use flux, significantly improves the corrosion resistance of the product, eliminates all kinds of pollution and pollution-free treatment equipment costs, and has good safety production conditions.
