Choosing the right SDS system is one of the most important decisions for anyone drilling into concrete, stone, or other masonry materials. Although rotary hammers look similar on the surface, the shank system inside the chuck determines how efficiently the hammer energy is transmitted, how fast you can drill, and which accessories you can use safely. SDS, SDS Plus, and SDS Max are the three core standards used worldwide, and each one is engineered for a different level of torque, impact energy, and drilling diameter. When contractors select the wrong SDS system, they often experience problems such as slow penetration, excessive bit wear, misalignment, or even dangerous tool incompatibility. This guide explains how SDS works, how each system differs, and how to choose the correct type for light-duty drilling, daily professional workloads, or heavy-duty demolition tasks. By the end, you will understand both the mechanical structure and the real-world applications that determine which SDS system belongs on your jobsite.
The SDS interface was introduced in 1975 through collaboration between Hilti and Bosch as a solution to the limitations of traditional round-shank hammer bits. Conventional bits relied on friction-based chuck tightening, which caused slippage under heavy percussion. SDS—short for the German Stecken, Drehen, Sichern (Insert, Twist, Secure)—uses a keyed shank design that eliminates slippage and allows for fast tool changes. Bosch later adopted "Special Direct System" as the international translation, but the core principle remains the same: provide a secure mechanical connection that supports both rotation and pneumatic hammering. This innovation marked a breakthrough in the industry, allowing hammer drills to transmit impact energy more efficiently and dramatically improving productivity in concrete drilling.
Unlike round shanks that rely on clamping force, SDS uses a slotted shank with precisely machined longitudinal keyways and retention indentations. When inserted into an SDS chuck, the keyways engage with internal drive pegs to transmit rotational torque, while the indentations allow the bit to move freely in a piston-like action during hammering. This sliding mechanism is essential: instead of the chuck repeatedly striking the bit, the hammer transfers energy directly to the flattened end of the shank. The design ensures that rotation is fixed, hammer action is efficient, and bit changes can be made quickly without adjusting jaws or tightening collars. It also prevents rotational slippage, a common issue in conventional chucks when drilling into dense masonry.
In an SDS system, the hammer inside the drill impacts only the back of the shank—not the chuck—so the chuck mass does not have to accelerate with every blow. This is why SDS drills produce significantly stronger and more consistent percussion. Less energy is lost, and more impact is delivered to the tip of the bit where the cutting edges fracture concrete. This mechanism also reduces user fatigue, because the operator only needs to apply moderate forward pressure; the hammer's internal piston does the heavy work. For tough aggregates or reinforced concrete, this improved impact transfer leads to faster hole production, reduced binding, and lower heat buildup.
Because the SDS shank slides within the chuck, proper lubrication is essential. Without grease, friction increases, heat rises rapidly, and the internal steel surfaces begin to gall or seize. A thin layer of SDS-rated grease on the grooves and shank end ensures smooth movement, consistent hammer action, and longer chuck life. Users should clean away dust and slurry deposits after each job, reapply grease, and inspect the groove edges for wear. Simple maintenance habits like these prevent bit jamming and preserve the tool's performance over the long term.
The original SDS interface introduced the core concept but has largely been replaced by SDS Plus in modern tools. With a 10 mm shank diameter, the early SDS system supported light-duty rotary hammers commonly used in residential or maintenance work. While still compatible with certain older tools, most manufacturers have transitioned entirely to SDS Plus due to improved holding strength, broader size ranges, and better availability. Today, standard SDS bits are rarely purchased new, though they remain relevant for servicing legacy equipment.
SDS Plus is by far the most widely used system today, built around a 10 mm shank with four optimized grooves. It supports bit diameters from roughly 4 mm to 30 mm (5/32" to 1-1/4") and lengths extending from 110 mm up to 1500 mm for deep applications. Contractors rely on SDS Plus for anchor holes, conduit paths, cable runs, and general-purpose concrete drilling. It also supports light chiselling when paired with a rotation-stop hammer. SDS Plus balances power, precision, and compact tool size, making it the go-to choice for electricians, HVAC technicians, and renovation crews who require consistent performance without the weight of a full SDS Max machine.
With an 18 mm shank diameter and a more robust groove geometry, SDS Max is engineered for large rotary hammers and professional demolition applications. Typical SDS Max bits range from 13 mm to 44 mm in diameter (1/2" to 1-3/4"), with lengths from 300 mm to over 530 mm for deep structural drilling. SDS Max hammers deliver significantly higher impact energy—ideal for breaking concrete, cutting large openings, drilling oversized anchor points, or chiselling in construction and civil engineering environments. The larger mass and torque capability make SDS Max the right choice when productivity and tool durability are essential under heavy loads.
The most visible difference is shank size: both SDS and SDS Plus use a 10 mm shank, while SDS Max increases this to 18 mm. SDS Max also features deeper and broader drive slots that allow for significantly higher torque transmission. Larger shanks prevent bending under load, reduce vibration, and allow the hammer to deliver more joules of impact energy with each stroke. This structural difference directly affects which drilling tasks each system can handle safely and efficiently.
SDS Plus hammers typically weigh between 2–4 kg, making them ideal for overhead or one-hand operation. SDS Max hammers weigh more, often 5–12 kg, and deliver far higher joule ratings for heavy concrete removal. Attempting to use a large SDS Max bit on an SDS Plus machine or apply SDS Plus bits in an SDS Max hammer with an adapter compromises safety and performance. Matching bit size with the correct power class ensures smooth drilling, fewer stalls, and longer tool life.
SDS Plus is best suited for small to medium diameters up to 30 mm, although long flute bits can reach deeper targets. SDS Max is designed for large-diameter penetrations, structural holes, and aggressive chiselling. When drilling extremely deep holes, rigidity and torque become critical—and SDS Max provides the stability required for these situations. For everyday medium-size holes, however, SDS Plus remains more efficient and easier to handle.
SDS Plus bits fit only SDS Plus chucks, and SDS Max bits fit only SDS Max chucks. Adapters exist but introduce movement, vibration, reduced torque, and potential early wear. Manufacturers strongly recommend direct matching between shank type and chuck for safety, accuracy, and bit longevity. Never force a mismatched bit—it can damage the chuck and create severe operational hazards.
The SDS family offers several important advantages over conventional round-shank bits:
• One-handed insertion and release with no jaws to tighten
• Zero rotational slippage due to keyed drive slots
• Stronger and more efficient hammer action
• Ability to use chisels and specialty accessories
• Faster jobsite workflow with rapid tool changes
These features make SDS the dominant system for masonry drilling worldwide.
SDS bits are more complex and expensive to manufacture, and they do not offer perfect centering accuracy for precision machining. They also require an SDS-compatible hammer drill; standard three-jaw chucks cannot hold SDS bits without an adapter. For metal, wood, or fine-tolerance drilling, round-shank bits remain the better choice.
SDS systems are not built for delicate materials, very small holes, or situations requiring tight accuracy such as machining steel plates or cabinet woodworking. Using SDS in inappropriate applications increases vibration, risks material damage, and leads to uneven hole quality.
Small and medium holes—anything up to around 30 mm—are typically handled best by SDS Plus. For diameters above this or for structural work such as installing rebar dowels, SDS Max is the correct system. Using an oversized bit on a small hammer reduces efficiency and wears out the gearbox quickly.
For drilling into soft brick or hollow block, SDS Plus is sufficient. For dense concrete with tough aggregates or heavily reinforced slabs, SDS Max delivers the impact energy needed to maintain progress. The more frequently you drill large holes, the more SDS Max becomes a necessity rather than an option.
Always match the bit to the tool class. SDS Max bits require SDS Max hammers to deliver stable torque, safe operation, and optimal penetration rates. Professionals often own both sizes: SDS Plus for daily utility work and SDS Max for heavy-duty or structural tasks.
SDS Plus bits are cheaper and stocked everywhere. SDS Max bits cost more but last longer under extreme load. Contractors who standardize their fleet see lower maintenance costs and fewer tool mix-ups. Mixed fleets are only beneficial when job requirements frequently range from light drilling to heavy demolition.
Insert the bit until it clicks firmly; no tightening is needed. To remove, pull back the sleeve and withdraw the bit. If a bit becomes stuck due to dust or heat expansion, let the tool cool and clean the shank before attempting removal.
Always apply a thin layer of SDS grease before inserting the bit. Clean away concrete dust, slurry, and debris that can accumulate in the grooves. Store bits dry and upright to avoid corrosion or bending.
Let the hammer do the work—excessive pressure slows drilling and increases wear. Withdraw the bit occasionally to clear debris from the hole. When chiselling, use rotation-stop mode and allow the bit to move freely without forcing it.
Wear appropriate PPE, including eye and hearing protection, gloves, and dust control equipment when drilling concrete. Inspect bit shanks and chucks regularly for deformation or cracking. Discontinue use immediately if you notice abnormal vibration or movement.
• Can SDS Plus bits be used in an SDS Max drill?
Only with an adapter, and performance will be reduced.
• Why does my SDS bit feel "loose" in the chuck?
This is normal—the bit must slide for hammering action.
• Do SDS bits need grease every time?
Yes. Lack of grease causes premature chuck wear.
• Is SDS Plus enough for reinforced concrete?
Yes for small holes; for large diameters, SDS Max is recommended.
• Are SDS-Top or other older systems still useful today?
Only for servicing older equipment; most modern tools use SDS Plus or SDS Max.
