When you need deeper, cleaner cuts in reinforced concrete and masonry—especially in tight access areas—a diamond ring saw blade is often the most efficient choice. SENMINE ring saw blades are built for professional cutting teams in construction, civil engineering, demolition, and utility work, combining laser-welded segments with stable alloy-steel bodies for consistent performance across demanding jobsite conditions. The periphery-driven ring saw concept is widely used for deep, one-side cutting compared with standard circular cutters.
Quick highlights
• Product type: Diamond ring saw blade (ring saw blades for concrete cutting)
• Cutting depth: Up to 390mm (XM500)
• Typical cutting materials: Reinforced concrete, brick, block, similar construction materials
• Cutting mode: Wet or dry compatible (wet cutting recommended when feasible for dust control)
• OEM/ODM: Size, segment, bond, branding, packaging
| Item Name | Segment Size (mm) | No. of Segments | Max Cutting Depth (mm) |
|---|---|---|---|
| XM370 | 32 × 10 × 4.2 | 22 | 270 |
| XM390 / 406 / 420 | 32 × 10 × 4.2 | 26 | 290 |
| XM425 | 32 × 12 × 4.2 | 26 | 310 |
| XM500 | 32 × 12 × 4.2 | 30 | 390 |
General specifications:
• Blade Material: Diamond + Alloy Steel
• Finishing: Polished and varnish painted
• Size Range: 350mm – 1200mm (14"–48")
• Segment Height: 10mm
• Surface Treatment: Polishing + Varnish
• Cutting Depth: Up to 390mm
• Cutting Materials: Reinforced concrete, bricks, and similar construction materials
• Cooling Method: Wet and dry compatible
Ring saw systems are commonly selected when crews need deep cuts from one side and better access in confined areas—an advantage frequently highlighted in ring saw applications and specifications.
• High-strength segment attachment helps reduce segment-loss risk during high-load cutting
• Stable cutting behavior supports consistent feed on reinforced concrete and dense masonry
• Built for sustained daily use in cutting, opening, and modification tasks
• Fast start and stable penetration on cement-rich materials
• Balanced wear for predictable tool life and easier cost-per-cut management
• Bond and grit can be customized for different aggregates and job conditions (OEM/ODM)
• Hydraulic-powered ring saws
• Gasoline-powered ring saws
• Available with or without drive wheel, depending on your saw design and purchasing preference
• If you're unsure which configuration fits, send your ring saw model details (or the drive-wheel spec) and we'll confirm compatibility before production.
SENMINE concrete ring saw blades are used for tasks where conventional circular blades are limited by cutting depth or access.
Typical applications
• Deep cutting in concrete walls and slabs
• Pre-cutting prior to chain saw finishing (for deeper completion cuts)
• Brick and block cutting for openings, remodeling, and structural modifications
• Demolition and rescue access cutting
• Utility work (pipe installation access cuts, trench-edge modifications, repair openings)
Wet and dry cutting are both possible, but jobsite safety and dust control should drive the choice.
Wet cutting (recommended when feasible)
• Helps control respirable crystalline silica dust exposure using engineering/work-practice controls—an approach emphasized by OSHA guidance for silica control.
• Improves cooling and can stabilize segment wear during longer cuts
Dry cutting (when wet cutting isn't practical)
• Use dust controls and appropriate PPE based on the work environment and local regulations
• Use controlled feed and avoid excessive pressure to reduce overheating and abnormal segment wear
More read:
To support distributor sourcing, project compliance, and repeatability across batches, SENMINE can provide clear traceability and QC checkpoints.
Traceability image: "Inspection Tag / Lot No. / Traceability"
• Each batch can be tracked by lot number for consistent procurement and repeat orders
• QC checkpoints cover segment welding stability, appearance, and dimensional consistency
• Documentation supports distributor/private label workflows and long-term supply reliability
As a diamond tool manufacturer and supplier, SENMINE supports OEM/ODM projects for distributors and private-label brands.
Customization options
• Blade diameter (350mm–1200mm) and segment dimensions
• With/without drive wheel configuration
• Segment bond formulation and grit selection
• Brand logo, labeling, packaging design
• Batch production for distributor/private-label orders
• Is XM370 a 14 inch ring saw blade?
Yes. XM370 corresponds to approximately a 14" ring saw blade size and provides up to 270mm max cutting depth.
• Which model offers the deepest cut?
XM500 provides the deepest max cutting depth in the standard lineup: up to 390mm.
• Can I use these concrete ring saw blades wet or dry?
Yes—both are supported. Wet cutting is commonly preferred where feasible for dust control and cooling.
• How do I confirm compatibility with my ring saw?
Send your ring saw type (gas or hydraulic), blade size requirement, and whether your setup needs a drive wheel. We'll confirm fitment before production.
• Do you support OEM branding and bulk orders?
Yes. We support OEM/ODM options including logo, packaging, and batch supply for distributor programs.
Tell us your required model/diameter, cutting material (reinforced concrete/brick/block), ring saw type (gas/hydraulic), and whether you need a drive wheel option.
